CMX EA-240A-240W PA Amplifier

Roll over image to zoom in

Status:In stock

Specification:

Model	EA-60A	EA-120A	EA-240A	EA-350A	EA-500A
Description	Mixer Amplifier with USB/SD/FM/Blue Tooth
Rated Power Output	60W	120W	240W	350W	500W
Speaker Outputs	100V or 70V & 4 Ohm-8 Ohm-16 Ohm
Connector	Mic1 input by balanced XLR with phantom power & VOX highest priority Mic/line switchable input 2-3 unbalanced 6.3mm jack Line1-2 inputs by RCA; Line output by RCA
Input	MIC1-3: 5-8mV, 600Ω; Line, 150-470mV, 10KΩ, unbalanced RCA
Line Out	0.775(0dBV)
Frequency Response	60Hz-15kHz(±3dB)
S/N Ratio	Line ≥ 85dB, Mic≥ 72dB
THD	Less than 0.5%
Protection	Short-circuit, clip, overload and high temp protection
Power Consumption	80W	150W	310W	450W	650W
Power Supply	AC230V; 50-60Hz
Dimension	484×405×88mm
Weight	7.0kg	7.1kg	8.6kg	8.7kg	8.9kg

Categories: Sound System Solution, PA Amplifier Brand: CMX

Mixer Amplifier with USB/SD/FM/Blue Tooth

EA-60A/EA-120A/EA-240A/EA-350A/EA-500A

Features:

Compact mini size public address amplifier
Tabletop mixer amplifier with Mp3 player, FM radio & blue tooth
Rate power output at 60W, 120W, 240W, 350W to 500W
Speaker output of 100V or 70V & 4 Ohm-8 Ohm-16 Ohm
Mp3 player with USB/SD input on front panel, IR remote control for Mp3 player, FM radio and blue tooth
LED indicators for power, clip, protect and signal
Mic1 of balanced XLR input with dipswitch of phantom power on/off & highest VOX priority on/off
Mic/line2-3 switchable inputs unbalanced 6.3mm jack
Line 1-2 input of RCA input and one RCA line output
Volume control for Mic1-3, line1-2, bass/treble and master
Complete amplifier protection includes short-circuit, clip, overload and high temp
AC230V power supply system
